KEY BENEFITS:
• Locking and unlocking the fastener only requires a quarter turn or a push.
• Fasteners can be locked and unlocked in a matter of seconds, saving time and reducing costs.
• Vibration resistant - performs well in even the most intensive applications.
• Camloc 1/4-Turn Quick Release Fasteners are safe and easy to use.
• A comprehensive range of fastener styles available in many sizes.
You can browse our range of quick release fasteners and quarter turn fasteners below. If you have a unique application then our engineering team, with their extensive knowledge of advanced fastener function can create a sophisticated solution that perfectly matches your requirements.
Contact us to speak to one of our engineers
KEY BENEFITS:
• Locking and unlocking the fastener only requires a quarter turn or a push.
• Fasteners can be locked and unlocked in a matter of seconds, saving time and reducing costs.
• Vibration resistant - performs well in even the most intensive applications.
• Camloc 1/4-Turn Quick Release Fasteners are safe and easy to use.
• A comprehensive range of fastener styles available in many sizes.
You can browse our range of quick release fasteners and quarter turn fasteners below. If you have a unique application then our engineering team, with their extensive knowledge of advanced fastener function can create a sophisticated solution that perfectly matches your requirements.
Contact us to speak to one of our engineers
-
5F Series - Quarter Turn
- Max. tensile strength 670 N, working load 450 N.
- Plastic washer stud assembly to protect decorative surfaces.
- Spring loaded receptacle.
-
V34F Series - Quarter Turn
- Max. tensile strength 44,482 N, working load 28,913 N.
- Capable of absorbing high tensile loads
- Capable of withstanding mechanical damage under severe operating conditions.
- Adjustable clamp lengths within a chosen grip length.
-
99F Series - Quarter Turn
- Max. tensile strength 700 N, working load 480 N
- Increased grip range
- Encapsulated design, splash-proof
- Externally threaded receptacles for use in castings or panels
-
50F 900N Series - Quarter Turn
- Max. tensile strength 900 N, working load 650 N
- Stud assembly incorporates a plastic washer to protect decorative surfaces
- Snap-in or clip-on spring loaded receptacle
- Snap-in grommet for quick stud installation without a retaining washer
-
50F 3700N Series - Quarter Turn
- Max. tensile strength 3,700 N, working load 2,600 N
- Small fastener giving high tensile load
- Flat receptacle
- High preload
-
2600 SERIES - QUARTER TURN
- Max. tensile strength 1,330 N, working load 900 N
- Small fastener giving a high tensile load
- Wide range of stud head styles and receptacles
-
2700 SERIES - QUARTER TURN
- Max. tensile strength 1,000 N, working load 700 N
- Small fastener giving a high tensile load
- Wide range of stud head styles and receptacles
-
D4002 SERIES - QUARTER TURN
- Max. tensile strength 4,700 N, working load 3,100 N
- Small fastener for high tensile load
- Large range of stud assemblies with fixed and floating receptacles
-
991F SERIES - QUARTER TURN
- Max. tensile strength 10,000 N, working load 7,000 N
- High tensile strength and preload
- Typical applications: Commercial vehicles, coaches, agricultural machinery, chemical engineering, heating systems etc
-
15F SERIES - PUSH BUTTON
- Max. tensile strength 1,330 N, working load 930 N
- Quick opening and closing by a push of the finger
- Easy installation with single hole mounting
-
715F SERIES - PUSH-TURN
- Max. tensile strength 700 N, working load 600 N
- Easy and economic clip-in installation for stud and receptacle
- Also suitable for automatic installation
-
